General Lee

Specifications of Vessel



Vessel Name: General Lee

Type: Single Screw Tugboat

Former Name:

Official Number: WN 1182 MD

Gross Tonnage:

Net Tonnage: Under 5

Total Weight: 15 Tons

Construction: Steel

Port Registry: Seattle, WA

Year Built: 1950

Last Rebuild: 2010

Survey: 2017

Vessel Dimensions

Overall Length: 26’

Registered Length: 25’ 11”

Overall Beam:

Registered Beam:

Draft: 4’

Air Draft:





Tank Capacity

Fuel: 500 Gallons Diesel. (Port and Starboard aft of Mid Ships)

Lube Oil:

Hydraulic Oil:

Miscellaneous:



Propulsion

Main Engine: Detroit Diesel 671 T

Horsepower: 350

Reduction Gear: Twin Disc MG 509 3 to 1 Ratio

Propeller: 26x 34   4 blade

Shaft Size: 2.5 “

Bollard Pull:

AC Power

Shore Connection: 30-amp twist lock

Generator: Portable Gas Driven 2000-Watt Honda Inverter Generator

Inverter: Cobra 1000 watt



DC Power

Batteries: 12 Volt Starting, 12 Volt House

Charging: Pro Mariner



Navigation/Communication

Radio VHF: 2-Standard Horizon GX-1600, 1 Standard Horizon GX-2200, 1- Standard Horizon GX-1700

Call Sign:

Radio SSB:

Loudhailer: Standard Horizon

Whistle: Portable

Radar:

Fathometer: Raytheon

GPS Plotter: Garmin

Autopilot:

Compass:

Weather Station:

AIS:

Radio Portable VHF: 1- Standard Horizon

Search Light: yes



Deck Equipment

Bow Winch: 12,000 lb Electric

Face Wire Winch:

Davit:

Lines: All Deck and Towlines are 1 Inch 3 Strand Poly Blue Steel Line 21,825 lb Breaking

Terminal Gear: Shackles, Hooks



 Salvage Equipment

Oil Spill Boom:

Oil Spill Pads: 2 Bales

Damage Control Supplies: DC Tarps, Splash Zone Putty, Assorted Wood Plugs, Assorted Wood Wedges, Epoxy Tape, Mechanical Rubber Plugs, Steel Patching Circles, Plywood Patching Pieces.





Safety Equipment

Survival Suits: 2 Adult

PFD’s: 4 Type 1 with Lights and whistles. 2 Work vests with Light and Whistle

Fixed Fire Suppression or Semi Portable: B-V Located in Wheelhouse

Portable Fire Extinguishers: 1- 5lb ABC Dry Chem, 2- 15 lb BC Carbon Dioxide

Portable Fire/Dewatering Pumps:  Honda/Pacer 2 Inch  12,000 GPH. Supplied with Suction and 50 feet of fire hose with nozzle.

SCBA:

First Aid: yes

Miscellaneous:



Accommodations

Wheelhouse:

Galley: N/A

Crew Quarters: N/A



Tools & Equipment

Welding: Lincoln Stick

Power Tools: 18 Volt De Walt Cordless

Hand Tools: Well Supplied

Pumps: Portable oil change and transfer pump

Portable Chargers: 12 volt

Miscellaneous:



Description Of Vessel:
